Description
- Built-in 50 CTCSS and 104 DTCS tones with Split Tone Function
- CS-2730 free download PC programming software
- Versatile scanning capability
- Squelch delay and squelch attenuator
- Sub band auto mute function
- Sub band busy beep function
- Auto repeater functions (Depending on the transceiver version)
- Auto power off
- Time-out-timer
- 16 DTMF auto dial memories
- Weather channel receive with weather alert
- CI-V remote control capability (through the OPC-478UC)
Specification
General
| Frequency coverage and mode
TX RX |
144-148, 430-450MHz 118-174, 375-550MHz* |
| Mode |
F2D, F3E |
| Type of emission |
F2D, F3E (FM) |
| No. of memory channels | 1052 channels (including 50 scan edges and 2 Call) |
| Frequency stability | ±2.5ppm |
| Operating temp. range |
–10°C to +60°C; 14°F to +140°F |
|
Frequency stability |
±3ppm (–10°C to +60°) |
|
Power supply requirement: |
13.8V DC ±15% |
| Current drain (at 7.4V DC):
Transmit Receive |
13A 1.8A/1.2A (Max. audio/Stand-by) |
| Antenna impedance | 50Ω (SO-239) |
| Dimensions (W×H×D) Main Unit Controller |
150×40×151 mm; 5.91×1.57×5.94 in 150×50×27.2 mm; 5.91×1.97×1.07 in |
| Weight (approx.) Main Unit Controller |
1.2 kg; 2.65 lb 140 g; 4.94 oz |
Transmitter
| Output power (at 13.8V DC)
TPE version |
50W, 15W, 5W
25W, 15W, 5W |
| Max. frequency deviation | ±5.0kHz/±2.5kHz (W/N) |
| Spurious emissions | Less than –60dBc |
| Microphone impedance | 60Ω (8-pin modular) |
Receiver
| Intermediate frequency A band B Band |
38.85MHz/450kHz 46.35MHz/450kHz |
| Sensitivity (at 12dB SINAD) | Less than –15dBμ |
| Selectivity | More than 60dB/55dB (W/N) |
| Spurious response rejection A band B band |
More than 60dB/55dB (V/U) More than 60dB/60dB (V/U) |
| Audio Output Power | More than 2W (10% dist. 8Ω) |
| External speaker connector | 2-conductor 3.5(d) mm 1/8"/4Ω |
| Receiver sensitivity FM/FM-N (12dB SINAD) 137–159.995MHz* 375–399.995MHz 500–550.000MHz 160–174.000MHz 400–499.995MHz* AM/AM-N (10dB S/N) 118–136.991MHz *Except amateur bands. |
–10dBμ –5dBμ –5dBμ –5dBμ –10dBμ 0dBμ |
