Description
- 750mW loud and intelligible audio with BTL amplifier and large 36mm speaker *Typical value with internal speaker
- 400-470MHz coverage
- Powerful 4W of output power
- IP54 and MIL-STD-810 rugged construction
- Large capacity Li-Ion battery pack, BP-265 provides 17.5 hours* of operating time * Typical operation. 5:5:90 duty cycle with auto power save.
- Integrated VOX function
- 200 memory channels, 1 call channel and 6 scan edges
- Built-in CTCSS and DTCS encoder/decoder
- 5 character alphanumeric display
- Priority, program, memory, skip and tone scanning
- 16 DTMF autodial memories
- Repeater lockout and busy channel lockout
- Time-out-timer
- Power save function and auto power off
- PC programmable (With optional CS-U80)
- Transceiver-to-transceiver cloning (Optional)
- Wide/narrow channel spacing
- Long or short squelch delay Dust Protection
Specification
General
| Frequency Coverage | 400-470MHz |
| Type of emissions | F2D,F3E (FM) |
| Number of channels | 207 channels |
| Antenna impedance | 50 Ω |
| Power supply requirement | 7.2V DC |
| Frequency Stability | +/- 2.5ppm (-20 ºC to +60 ºC) at 25ºC |
Transmitter
| Output power (at 7.2V) | 4.0/2.0/0.5W (Hi/Mid/Low) |
| Max. freq deviation | +/- 5.0kHz/ +/-2.5kHz (Wide/Narrow) |
| Spurious emissions | Less than -65dB |
| External microphone connector | 3-conductor 2.5(d)mm |
Receiver
| Sensitivity | 0.2 µV |
| Squelch Sensitivity | 0.11 µV |
| Selectivity | 70dB/60dB |
| Intermodulation | 70dB/70dB |
| Spurious and image rejection | 70dB |
| Audio Output Power |
750mW 400mW |
| External Speaker Connector | 3-conductor 3.5 |
