Description
-
Icom Custom High Power Handling Capacity Speaker for 1500 mW Powerful Audio
-
IP67 Waterproof and Dust-tight Protection
-
5.5 W/4 W (VHF/UHF) of Output Power
-
Up to 10 Hours of Operating Time with the Supplied Waterproof Battery
-
128 Memory Channels and Eight Zones
-
Eight Character Alphanumeric Display
-
Built-in CTCSS and DTCS Encoder/Decoder
-
Eight DTMF Autodial Memories
-
MDC 1200 PTT ID and BIIS 1200 PTT ID
-
Inversion Voice Scrambler (16 code) for Private Conversations
-
Channel Announcement of the Operating Channel Number
-
Seven Programmable Buttons with Shift Key Function
-
16 Scan Lists and Priority Scan Functions
-
Hands-Free Operation with the Optional Headset
Specification
General
| Frequency Coverage | 136MHz–174MHz |
| Type of emission | 16K0F3E, 11K0F3E (25/12.5kHz) |
| Number of channels | 128 |
| Antenna impedance | 50Ω |
| Power supply requirement | 7.5V DC |
| Operating temperature range | −30°C to +60°C (Radio only) |
| Frequency stability | ±2.5ppm |
| Current drain (approx.) |
Tx High: 1.5A Rx Max. audio/Stand-by: 500 mA |
| Dimensions (W×H×D) (Projections not included) |
52.2×111.8×22.3 mm (with BP-278) |
| Weight | 230g (with BP-278) |
Transmitter
| Output power (at 7.5V) | 5.5/2.0/1.0W (Hi/L2/L1) |
| Max. frequency deviation | ±5.0kHz/±2.5kHz (Wide/Narrow) |
| Spurious emissions | 70dB min. |
| Ext. microphone connector | 3-conductor 2.5(d)mm (1/10″)/2.2kΩ |
Receiver
| Sensitivity | 0.25μV typ. (at 12dB SINAD) |
| Squelch sensitivity | 0.25μV typ. (at threshold) |
| Adjacent channel selectivity | 76dB/53dB typ. (Wide/Narrow) |
| Intermodulation | 74dB typ. |
| Spurious response | 70dB min. |
| Audio output power |
Internal SP: 1500 mW typ. (8Ω load) External SP: 400 mW typ. (8Ω load) |
| External speaker connector | 3-conductor 3.5(d)mm (1/8″)/8Ω |
